Intellian v100NX User Manual

44
Installing ACU
LAN Ports
Pin Signal
1
Tx-
2
Tx+
3
Rx-
4
NC
5
NC
6
Rx+
7
NC
8
NC
LAN 1~4 Ports
Antenna Control Unit (ACU):
LAN Ports
5
4
3
2
1
Pins
Female Male
Connector
Threads
5
3
4
1
2
Sockets
Connector
Threads
5
4
3
2
1
Pins
Female Male
Connector
Threads
5
3
4
1
2
Sockets
Connector
Threads
NMEA 2000 Connector
NMEA 2000 Connector
(Male Connector Type)
NMEA 2000 Connector
(Female Connector Type)
Antenna Control Unit (ACU):
Pin Signal
1 Shield
2
NET-S,
(power supply positive, +V)
3
NET-C,
(power supply common, -V)
4 NET-H, (CAN-H)
5 NET-L, (CAN-L)
Cable Connector:
Cable Connector:
