Intellian v45C User Manual

84
v45C - Maritime VSAT Antenna System
No. Item Description
1
Modem Setting Sets parameters for the modem.
2
Modem
Sets the interface between the ACU and the satellite modem.
• Select Modem: Select your modem type from the Select Modem drop-down
list (IDIRECT OPENAMIP, COMTECH ROAM, SATLINK VACP, NEWTEC AMIP)
for loading a pre-conguration for the type of modem used. The settings
related to the modem interface will be set automatically once the modem
type is selected. When you select USER SETTING the other settings can be
changed independently.
• Modem Port: Select a proper data communication port of the ACU for the
satellite modem interface.
• Modem Protocol: Select a proper communication protocol of the ACU for the
modem interface.
• GPS Out Sentence: Select the GPS out sentence type.
• Use Tx Mute: Select whether to use the Tx Mute function for the modem or
not.
• Use Modem Lock: Select whether to use Modem Lock function for the
modem or not.
• Tx Mute: This function can be edited when User Setting option is selected
in the Select Modem menu. It selects the Tx Mute option. The Tx Mute is
a transmit inhibit output from the ACU to disable/mute the modem transmit
through a 5 V (HIGH) or 0 V (LOW) current whenever the antenna is blocked,
searching, or pointed 0.5 degrees off from peak satellite position.
• Modem Lock: This function can be edited when User Setting option is
selected in the Select Modem menu. It selects the Modem Lock option. The
Modem Lock provides a logic input through a 5V (HIGH) or 0 V (LOW) current
to the ACU to identify when the system is on the correct satellite.
Click the Apply button to apply the settings to the system.
3
Modem Port
Conguration
This function is available after performing the "8.8.3 iARM Save & Reboot" on
page 69.
Sets the ACU's internal IP address, routing, and ports.
• IP Address: Enter the network IP address.
• Subnet Mask: Enter the subnet mask.
• Gateway: Enter the gateway.
• MODEM IP: Enter the modem IP.
• DNS: Enter the current default DNS address.
• NAT Routing: Select the NAT routing (Enable / Disable).
• TCP Modem Protocol Port: Enter the TCP port number for modem protocols
using TCP as transport.
• UDP Modem Protocol Port: Enter the UDP port number for modem protocols
using UDP as transport.
Click the Apply button to apply the settings to the system.
