85
Using AptusNX
No. Item Description
4
Modem
Connection
Enter the connection information of the modem (IDIRECT OPENAMIP,
COMTECH ROAM, SATLINK VACP, NEWTEC AMIP).
• Modem IP: Enter the modem IP address.
• Port: Enter the connection port.
• ID: Enter the connection ID.
• Password: Enter the connection password.
• Auto Connect: By enabling the auto connect, the connection information is
saved and the modem is connected automatically when the system reboots.
• Last Update Date: Displays the last update date and time.
• Connect: Displays last updated data and time of the modem data.
• Rx SNR: Displays the Rx SNR data.
5
Beam Selector
This menu can be edited when IDIRECT Open AMIP Modem option is selected in the
Select Modem menu.
Selects the target satellite that you want to track.
• Beam List: Choose the target satellite in the list.
• Apply: Click the Apply button to apply the selected beam to the system, it
will switch to the beam desired.
• Lock: Within condition given for test or commissioning, if the user wishes to
stay on a selected beam, the user can lock the beam by clicking the Lock
button. This will lead modem stays with the user-selected beam.
• Reboot: If you do not want to lock the beam, click the Reboot button.
• Refresh: Click the Refresh button to load the latest satellite list.
6
Newtec Modem
Monitor
This menu can be edited when NEWTEC AMIP option is selected in the Select Modem
menu.
Sets the Newtec Modem options.
• dBm: Displays the signal level from the Newtec Modem.
• Es/NO: Displays the Es/NO value from the Newtec Modem.
• Ntc_s Request Delay Time (ms): Set the delay time of the system for
receiving the signal level (dBm) and Es/NO value from the Newtec Modem.
Click the Apply button to apply the settings to the system. Then perform the
"8.8.3 iARM Save & Reboot" on page 69.
To Next Page
