(Option 2: Using Library Type)
Description
• Step 1: choose the "Library" button on
the "Tracking Type".
• Step 2: select a satellite in satellite
library list then click the "Start
Searching" button.
Please wait until antenna terminal is
tracking to the satellite. The bow offset
will be set up automatically.
• Step 3: check the "Lock On" mark and
click the "Save Satellite" button in the
"Bow Offset" menu to save the bow
offset information to ACU.
If you have no problems, click the "Next"
button.
ü
Step 4: Set Bow Offset
For setting bow offset, need to select a trackable satellite. There are two satellite tracking methods. Select the
desired tracking type. When Antenna tracks to the satellite selected, the bow offset will be set up automatically
based on information of GPS.
(Option 1: Using Beam Switch Type)
Description
• Step 1: choose the "Beam Switch"
button on the "Tracking Type".
• Step 2: select a satellite in beam list
then click the "Apply" button.
Please wait until antenna terminal is
tracking to the satellite. The bow offset
will be set up automatically.
• Step 3: check the "Lock On" mark and
click the "Save Satellite" button in the
"Bow Offset" menu to save the bow
offset information to ACU.
If you have no problems, click the "Next"
button.
