Intermec EasyCoder PC4—Service Manual 55
Chapter 7—Main Board
7.6 Internal Memory
e EasyCoder PC4 has, as a standard, a flash memory of 1024K and an
RAM memory of 2048K fitted on the main board.
e memory is organized as follows:
Flash Memory
Firmware and 5 std. bitmap fonts 774K
User available (forms, graphics, soft fonts)
250K
Sum
1024K
RAM Memory
Firmware 576K
Print buffer
1050K
Reserved RAM 422K
Sum 2048K
e internal memory can be expanded using an optional flash memory
cartridge, see Chapter 9.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
