Intermec EasyCoder PD4—Service Manual 51
Chapter 8—Rewinder Module
Installation
The rewinder module can easily be fi tted by the operator following these
steps.
1 Remove the screw that holds the front cover. Remove the front cover.
2 Open the side door and remove the rewinder option cover plate, which
is held by two screws.
3 Remove the U-shaped clip and attach the rewinder unit to the center
section using the four screws included in the kit.
Cover plate
Front cover
Screw
