Intermec EasyCoder PD4 Service Manual

Intermec EasyCoder PD4—Service Manual 59
Chapter 10—Cutter
Installation
1 Remove the screw that holds the front cover. Remove the front cover.
2 Open the side door and remove the tear bar, which is held by two Phil-
lips screws.
3 Attach the cutter mechanism to the printer using the two Phillips screws
and washers included in the kit.
Tear bar
Screws
Front cover
Screw
