122 EasyCoder PX6i User’s Guide (Fingerprint version)
Appendix A — Technical Data
Printing
Print Technique Direct Thermal and Thermal Transfer
Printhead Resolution 8 dots/mm (203.2 dpi) or
11.81 dots/mm (300 dpi)
Print Speed (variable) 100 to 225 mm/sec.
(≈ 4 to 8.85 in./sec.)
Print Width (max) 167.4 mm (6.59 in.)
Print Length (max) 32767 dots
= 409.5 cm (161.25 in.) at 203.2 dpi
1
= 277.5 cm (109.23 in.) at 300 dpi
1
Media Width (min/max) 76 to 170 mm (3 to 6.69 in.)
Media Roll Diameter (max) 213 mm (8.38 in.)
205 mm (8.07 in.)
Tear-off
Peel-off
Media Roll Core Diameter 38 to 40 mm (1.5 in.) or
76 mm (3 in.) with adapters fi tted
Ribbon Width (min/max)
76.2 to 168 mm (3 to 6.61 in.)
Ribbon Roll Diameter
(outer), max.
80 mm (3.15 in.)
≈ 450 m (1476
ft) of ribbon
Ribbon Roll Core Dia-
meter (inner)
25 mm (1.00 inches)
Print Directions 4
Modes of Operation
Tear-Off (Straight-through) Yes
Cut-Off Option With cutter
Peel-Off (Self-strip) Option With rewinder
Firmware
Operating System Intermec Fingerprint v8.30 Incl. Direct
Protocol
Smooth Fonts TrueDoc and TrueType fonts
Resident scalable fonts 15 Unicode fonts
2
Resident bar codes 59
Startup Program (std) Intermec Shell v8.2
Physical Measures
Dimensions (W × L × H) 335 × 482 × 238 mm
(13.2 × 19.0 × 9.4 in)
Weight (excluding media) 14.8 kg (32.6 pounds)
