Intermec EasyCoder PX6i User Manual

124 EasyCoder PX6i User’s Guide (Fingerprint version)
Appendix A — Technical Data
Accessories and Options
Integral Self-strip Unit with
Liner Takeup
Option
3,4
For peel-off
operation
Fan-fold Guide Option
5
Cutter Option
5
Label Taken Sensor Option
3,4
Real Time Clock Option
3,4
10+ years life
Parallel Interface Board Option
3,4
IEEE 1284
Double Serial Interface
Board
Option
3,4
2 serial ports
Serial/Industrial Interface
Board
Option
3,4
1 serial port +
1 industrial
interface port
EasyLAN Ethernet Inter-
face
Option
3,4
EasyLAN Wireless Inter-
face
Option
3,4
Built-in Alphanumeric
Keyboard
Option
3,4
External Alphanumeric
Keyboard
Option
5
CompactFlash Cards for
various purposes
Option
5
8MB-1GB
CompactFlash Protection
Plate
Option
5
1
/. The max. print length is also restricted by the amount of free SDRAM memory.
2
/. Latin, Greek, and Cyrillic fonts according to Unicode standard are included.
3
/. Factory installed option
4
/. Field-installable kit. Installation should be performed by a service technician.
5
/. Operator-installable option.

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
