SECTION 5—SEAT
Solara
™
and Solara
™
Limited 30 Part No 1085787
17½ INCH SEAT-TO-FLOOR
18 INCH SEAT-TO-FLOOR
-OR-
NOTE: The seat-to-floor heights are based on pneumatic tires and pneumatic tires with flat free
inserts. If wheelchair is equipped with urethane tires, subtract ¼ inch from the measurements listed
above. All heights are measured with properly inflated new tires. These heights can vary ± ¼ inch
due to tire wear.
*NOTE: A 2-inch lower seat-to-floor is obtainable when attaching the seat pan/seating system to
the crossmembers instead of the seat rails.
FORK CASTER REAR WHEEL AXLE PLATE SEAT-TO-FLOOR
6 inch/
Bottom Hole
6 inch 20 inch Rounded Down/
Top 2 Holes
17½ inch
*15½ inch
FORK CASTER REAR WHEEL AXLE PLATE SEAT-TO-FLOOR
8 inch/
Top Hole
8 inch 12 inch Rounded Up/
Middle 2 Holes
18 inch
*16 inch
FORK CASTER REAR WHEEL AXLE PLATE SEAT-TO-FLOOR
8 inch/
Top Hole
8 inch 20 inch Rounded Down/
Top 2 Holes
18 inch
*16 inch
To Next Page
