SECTION 5—SEAT
Part No 1085787 29 Solara
™
and Solara
™
Limited
16¾ INCH SEAT-TO-FLOOR
17 INCH SEAT-TO-FLOOR
17½ INCH SEAT-TO-FLOOR
NOTE: The seat-to-floor heights are based on pneumatic tires and pneumatic tires with flat free
inserts. If wheelchair is equipped with urethane tires, subtract ¼ inch from the measurements listed
above. All heights are measured with properly inflated new tires. These heights can vary ± ¼ inch
due to tire wear.
*NOTE: A 2-inch lower seat-to-floor is obtainable when attaching the seat pan/seating system to
the crossmembers instead of the seat rails.
FORK CASTER REAR WHEEL AXLE PLATE SEAT-TO-FLOOR
6 inch/
Middle Hole
6 inch 12 inch Rounded Down/
Top 2 Holes
16¾ inch
*14¾ inch
FORK CASTER REAR WHEEL AXLE PLATE SEAT-TO-FLOOR
8 inch/
Upper Hole
6x2 inch 12 inch Rounded Down/
Top 2 Holes
17 inch
*15 inch
FORK CASTER REAR WHEEL AXLE PLATE SEAT-TO-FLOOR
6 inch/
Bottom Hole
6 inch 12 inch Rounded Down/
Middle 2 Holes
17½ inch
*15½ inch
