Goodrive35 inverters Function codes
165
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P21.17
Location
figures
reference
Set the position place of digital setting
Actual position =P21.17*P21.11/P21.12
0~65535
0
○
P21.18
Positionin
g speed
setting
Positioning speed setting
0:P21.19 digital setting
1: AI1 setting
2: AI2 setting
3: AI3 setting
4: HDI setting
0
○
P21.19
Digital
setting of
the
positionin
g speed
Select the positioning speed
0.1~100.0% of the Max. frequency
20.0%
○
P21.20
Positionin
g ACC
time
Set the ACC/DEC time during the positioning
Position ACC time is the interval time accelerating
from 0Hz to P00.03
Position DEC time is the interval time decelerating
from P00.03 to 0Hz
3.00s
○
P21.21
Positionin
g DEC
time
3.00s
○
P21.22
Hold time
of the
positioned
finished
Set the hold waiting time after arriving to the target
position
0.000~60.000s
0.100s
○
P21.23
Origin
search
speed
Reserved.
0.00~50.00Hz
2.00Hz
○
P21.24
Origin
position
offset
Reserved.
0~64000
0
○
