Goodrive35 inverters Basic operation instruction
205
Function
code
Name
Detailed instruction of parameters
Default
value
0:Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after
receiving the stop commands
P08.45
UP terminals frequency
changing ratio
0.01~50.00 Hz/s
0.50 Hz/s
P08.46
DOWN terminals
frequency changing ratio
0.01~50.00 Hz/s
0.50 Hz/s
P17.00
Setting frequency
Display current set frequency of the
inverter
Range: 0.00Hz~P00.03
0.00Hz
P17.02
Ramp reference frequency
Display current ramp given frequency of
the inverter
Range: 0.00Hz~P00.03
0.00Hz
P17.14
Digital adjustment
Display the adjustment through the
keypad of the inverter.
Range : 0.00Hz~P00.03
0.00Hz
7.9 Analog input
Goodrive35 series inverters have three analog input terminals and 1 high-speed pulse input
terminals (of which, AI1 and AI2 are 0~10V/0~20mA and Al can select voltage input or current input
by J3, AI2 can select voltage input or current input by J4 and AI3 is for -10~10V ) as the standard
configuration. The inputs can be filtered and the maximum and minimum values can be adjusted.
