INVT Goodrive 35 Series

Goodrive35 inverters Basic operation instruction
196
Function
code
Name
Detailed instruction of parameters
Default
value
P12.05
Rated current of
asynchronous motor 2
0.8~6000.0A
Depend
on model
P12.06
Stator resistor of
asynchronous motor 2
0.001~65.535Ω
Depend
on model
P12.07
Rotor resistor of
asynchronous motor 2
0.001~65.535Ω
Depend
on model
P12.08
Leakage inductance of
asynchronous motor 2
0.1~6553.5mH
Depend
on model
P12.09
Mutual inductance of
asynchronous motor 2
0.1~6553.5mH
Depend
on model
P12.10
Non-load current of
asynchronous motor 2
0.1~6553.5A
Depend
on model
P12.15
Rated power of
synchronous motor 2
0.1~3000.0kW
Depend
on model
P12.16
Rated frequency of
synchronous motor 2
0.01Hz~P00.03(the Max. frequency)
50.00Hz
P12.17
Number of poles pairs for
synchronous motor 2
1~128
2
P12.18
Rated voltage of
synchronous motor 2
0~1200V
Depend
on model
P12.19
Rated current of
synchronous motor 2
0.8~6000.0A
Depend
on model
P12.20
Stator resistor of
synchronous motor 2
0.001~65.535Ω
Depend
on model
P12.21
Direct axis inductance of
synchronous motor 2
0.01~655.35mH
Depend
on model
P12.22
Quadrature axis
inductance of
synchronous motor 2
0.01~655.35mH
Depend
on model
P12.23
Back EMF constant of
synchronous motor 2
0~10000
300
7.7 Start-up and stop control
The start-up and stop control of the inverter includes three states: start after the running command
