Goodrive35 inverters Basic operation instruction
226
Function
code
Name
Detailed instruction of parameters
Default
value
26:Bus voltage established
27: Reserved 28: Pulse superposing 29:
Reserved
30: Positioning finished
31: Spindle returning finished
32: Spindle scaling finished
33: Speed limiting
34: Low bus voltage
35: Reserved
36: Speed/position switching finished
37~40: Reserved
P06.05
Polarity of output
terminals
0x00~0x0F
0x00
P06.06
Y1 switch-on delay time
0.000~50.000s
0.000s
P06.07
Y1 switch-off delay time
0.000~50.000s
0.000s
P06.08
HDO switch-on delay time
0.000~50.000s
(valid only when P06.00=1)
0.000s
P06.09
HDO switch-off delay time
0.000~50.000s
(valid only when P06.00=1)
0.000s
P06.10
RO1 switch-on delay time
0.000~50.000s
0.000s
P06.11
RO1 switch-off delay time
0.000~50.000s
0.000s
P06.12
RO2 switch-on delay time
0.000~50.000s
0.000s
P06.13
RO2 switch-off delay time
0.000~50.000s
0.000s
P07.38
The Max. temperature at
current fault
0
P17.13
Digital output terminals
state
0
7.13 Simple PLC
Simple PLC function is also a multi-step speed generator. The inverter can change the running
frequency, direction to meet the need of processing according to the running time automatically. In
the past, this function needs to be assisted by external PLC, but now the inverter can realize this
function by itself.
The series inverters can control 16-stage speed with 4 groups of ACC/DEC time.
