INVT Goodrive 35 Series User Manual

Goodrive35 inverters Appendix B
309
protection
Frequency
0...400 Hz
Frequency
resolution
0.01 Hz
Current
Refer to Ratings
Power limit
1.5 · PN
Field weakening
point
10...400 Hz
Carrier frequency
4, 8, 12 or 15 kHz(in scalar control)
B.4.1 EMC compatibility and motor cable length
To comply with the European EMC Directive (standard IEC/EN 61800-3), use the following
maximum motor cable lengths for 4 kHz switching frequency.
All frame sizes (with external EMC filter)
Maximum motor cable length, 4 kHz
Second environment (category C3)
30
First environment (category C2)
30
Maximum motor cable length is determined by the drive’s operational factors. Contact the
local representative for the exact maximum lengths when using external EMC filters.
B.5 Applicable standards
The inverter complies with the following standards:
EN ISO 13849-1: 2008
Safety of machinery-safety related parts of control systems -
Part 1: general principles for design
IEC/EN 60204-1:2006
Safety of machinery. Electrical equipment of machines. Part
1: General requirements.
IEC/EN 62061: 2005
Safety of machinery – Functional safety of safety-related
electrical,electronic and programmable electronic control
systems
IEC/EN 61800-3:2004
Adjustable speed electrical power drive systems. Part 3: EMC
requirements and specific test methods
IEC/EN 61800-5-1:2007
Adjustable speed electrical power drive systems – Part 5-1:
Safety requirements – Electrical, thermal and energy
IEC/EN 61800-5-2:2007
Adjustable speed electrical power drive systems – Part 5-2:
Safety requirements. Functional.
