INVT Goodrive 35 Series User Manual

Goodrive35 inverters Basic operation instruction
207
Function
code
Name
Detailed instruction of parameters
Default
value
P05.44
Zero-drift value of AI3
P05.42~P05.46
0.00V
P05.45
Zero-point deadzone
voltage of AI3
0.00~10.00V
0.04V
P05.46
Upper limit of AI3
P05.35~10.00V
10.00V
P05.47
Corresponding setting of
the upper limit of AI3
-300.0%~300.0%
100.0%
P05.48
AI3 input filter time
0.000s~10.000s
0.030s
P05.49
HDI high-speed pulse
input function
selection
0:Frequency setting input, frequency
setting source
1:Counter input, high-speed pulse
counter input terminals
2:Length counting input, length counter
input terminals
0
P05.50
Lower limit frequency of
HDI
0.00 kHz ~ P05.43
0.00kHz
P05.51
Corresponding setting of
HDI low frequency setting
-300.0%~300.0%
0.0%
P05.52
Upper limit frequency of
HDI
P05.41~50.00kHz
50.00kHz
P05.53
Corresponding setting of
upper limit frequency of
HDI
-300.0%~300.0%
100.0%
P05.54
HDI frequency input filter
time
0.000s~10.000s
0.030s
7.10 Analog output
Goodrive35 series inverters have 2 analog output terminals (0~10V or 0~20mA) and 1 high speed
pulse output terminal. Analog output signal can be filtered and the maximum and minimum values
can be adjusted. The analog output signals can be proportional to motor speed, output frequency,
output current, motor torque, motor power, etc. 100% of the output current is relative to 2 times of
the rated current of the inverter.
