INVT Goodrive 35 Series User Manual

Goodrive35 inverters Product overview
20
Model
Rated
output
power(kW)
Rated
input
current(A)
Rated
output
current(A)
Carrier
frequency
(kHz)
GD35-200G-6-C1/D1/H1
200
210
216
1~15(2)
GD35-220G-6-C1/D1/H1
220
230
240
1~15(2)
GD35-250G-6-C1/D1/H1
250
255
274
1~15(2)
GD35-280G-6-C1/D1/H1
280
286
300
1~15(2)
GD35-315G-6-C1/D1/H1
315
334
328
1~15(2)
GD35-350G-6-C1/D1/H1
350
360
380
1~15(2)
GD35-400G-6-C1/D1/H1
400
411
426
1~15(2)
GD35-500G-6-C1/D1/H1
500
518
540
1~15(2)
GD35-560G-6-C1/D1/H1
560
578
600
1~15(2)
GD35-630G-6-C1/D1/H1
630
655
680
1~15(2)
Note:
1. The input current of inverters 22~350kW is detected when the input voltage is 660V and
there is no DC reactors and input/output reactors.
2. The input current of inverters 400~630kW is detected when the input voltage is 660V and
there are input reactors.
3. The rated output current is defined when the output voltage is 660V.
4. The output current can not exceed the rated output current and the output power can not
exceed the rated output power in the voltage range.
3.7 I/O PG card selection
Model
Instruction
Specification
EC-PG301-05
5V I/O incremental
PG card
5V incremental ABZ encoder, support differential
input Max. 200kHz
EC-PG301-12
12V I/O incremental
PG card
12V incremental ABZ encoder, support differential,
OC and push-pull input, Max. 100kHz
EC-PG301-24
24V I/O incremental
PG card
24V incremental ABZ encoder, support differential,
OC and push-pull input, Max. 100kHz
EC-PG304-05
5V I/O rotary
transformer PG card
Rotary transformer encoder, Max. 500kHz
EC-PG305-12
5V/12V I/O
multi-function
5V/12V incremental ABZ encoder, support
pulse/direction differential input and
www.barghmaher.ir
