INVT Goodrive 35 Series User Manual

Goodrive35 inverters Basic operation instruction
211
Function
code
Name
Detailed instruction of parameters
Default
value
P06.21
AO1 output filter time
0.000s~10.000s
0.000s
P06.22
Lower output limit of AO2
-300.0%~P06.24
0.0%
P06.23
Corresponding AO2
output of lower limit
0.00V~10.00V
0.00V
P06.24
Upper output limit of AO2
P06.18~300.0%
100.0%
P06.25
The corresponding AO2
output of upper limit
0.00V~10.00V
10.00V
P06.26
AO2 output filter time
0.000s~10.000s
0.000s
P06.27
Lower output limit of HDO
-300.0%~P06.29
0.0%
P06.28
Corresponding HDO
output of lower limit
0.00~50.00kHz
0.0kHz
P06.29
Upper output limit of HDO
P06.23~300.0%
100.0%
P06.30
Corresponding HDO
output of upper limit
0.00~50.00kHz
50.00kHz
P06.31
HDO output filter time
0.000s~10.000s
0.000s
7.11 Digital input
Goodrive35 series inverters have 8 programmable digital input terminals and 1 open circuit
electrode output terminal in the standard configuration. All functions of the digital input terminals
are programmable by the function codes. Open collector pole input can be selected into high
speed pulse input terminal or common switch input terminal by function code. When selected into
HDI, the user can select HDI high speed pulse input as frequency given, counting input or length
pulse input by setting.
