Goodrive35 inverters Basic operation instruction
221
Function
code
Name
Detailed instruction of parameters
Default
value
P05.25
Switch-off delay of S6
terminal
0.000~50.000s
0.000s
P05.26
Switch-on delay of S7
terminal
0.000~50.000s
0.000s
P05.27
Switch-off delay of S7
terminal
0.000~50.000s
0.000s
P05.28
Switch-on delay of S8
terminal
0.000~50.000s
0.000s
P05.29
Switch-off delay of S8
terminal
0.000~50.000s
0.000s
P05.30
Switch-on delay of HDI
terminal
0.000~50.000s
0.000s
P05.31
Switch-off delay of HDI
terminal
0.000~50.000s
0.000s
P07.37
Bus voltage at current
fault
0
P17.12
Digital input terminals
state
0000~01FF
0
7.12 Digital input
Goodrive35 series inverters have 2 relay output terminals and 1 Y output terminal and 1 high
speed pulse output terminal in the standard configuration. All functions of the digital input terminals
are programmable by the function codes. Open collector pole input can be selected into high
speed pulse input terminal or common switch input terminal by function code.
