Goodrive35 inverters Basic operation instruction
225
Function
code
Name
Detailed instruction of parameters
Default
value
P06.00
HDO output
0:Open collector pole high speed pulse
output
1: Open collector pole output
0
P06.01
Y1 output
0:Invalid
1:In operation
2:Forward rotation operation
3:Reverse rotation operation
4: Jogging operation
5:The inverter fault
6:Frequency degree test FDT1
7:Frequency degree test FDT2
8:Frequency arrival
9:Zero speed running
10:Upper limit frequency arrival
11:Lower limit frequency arrival
12:Ready for operation
13:Pre-magnetizing
14:Overload pre-alarm
15: Underload pre-alarm
16:Completion of simple PLC stage
17:Completion of simple PLC cycle
18: Reserved
19: Reserved
20: Reserved
21: Reserved
22: Reserved
23:MODBUS communication virtual
terminals output
24:PROFIBUS/CANopen communication
virtual terminals output
25: Ethernet communication virtual
terminals output
0
P06.02
HDO output
0
P06.03
Relay RO1 output
1
P06.04
Relay RO2 output
5
