INVT Goodrive 35 Series User Manual

Goodrive35 inverters Basic operation instruction
224
Set value
Function
Instructions
16
Simple PLC stage
completion
Output signal if the simple PLC stage is completed.
17
Simple PLC cycle
completion
Output signal if the 1 simple PLC cycle is completed.
18
Reserved
Reserved
19
Reserved
Reserved
20
Reserved
Reserved
21
Reserved
Reserved
22
Reserved
Reserved
23
MODBUS communication
virtual terminal output
Output corresponding signal according to the setting
value of MODBUS. Output ON signal if the setting
value is 1 and output OFF signal if the setting value
is 0.
24
POROFIBUS communication
virtual terminal output
Output corresponding signal according to the setting
value of PROFIBUS/CANOPEN. Output ON signal if
the setting value is 1 and output OFF signal if the
setting value is 0.
25
Ethernet virtual terminal
output
Output the corresponding signal according to the
Ethernet signal. Output ON when setting as1 and
output OFF when setting as 0.
26
Bus voltage established
Output ON according to the establishment of bus
voltage
27~29
Reserved
30
Positioning finished
Output ON when the positioning is finished
31
Spindle returning finished
Output ON when the returning is finished
32
Spindle scaling finished
Output ON when the scaling is finished
33
Speed limiting
Output ON when the speed is the upper or lower limit
34
Low bus voltage
Output ON when the value is below P8.27
35
Underload stopping output
If the enabling bit of P08.26 is valid, and it is in the
underload state, ON signal will be output
36
Speed/position switching
finished
When the speed is switched to position control,
output ON signal
Relative parameters list:
