INVT Goodrive 35 Series User Manual

Goodrive35 inverters Basic operation instruction
223
The below table is the option of the four function parameters and selecting the repeated output
terminal function is allowed.
Set value
Function
Instructions
0
Invalid
The output terminal has no function.
1
Running
Output ON signal when the inverter is running and
there is frequency output.
2
Forward running
Output ON signal when the inverter is running
forward and there is frequency output.
3
Reverse running
Output ON signal when the inverter is running
reverse and there is frequency output.
4
Jogging
Output ON signal when the inverter is jogging and
there is frequency output.
5
Inverter fault
Output ON signal when the inverter is in fault
6
FDT1
Please refer to P08.32 and P08.33 for detailed
information.
7
FDT2
Please refer to P08.34 and P08.35 for detailed
information.
8
Frequency arrival
Please refer to P08.36 for detailed information.
9
Zero-speed running
Output ON signal when the output frequency and
given frequency of the inverter is 0 at the same time.
10
Upper-limit frequency arrival
Output ON signal when the running frequency of the
inverter is the upper limit frequency.
11
Upper-limit frequency arrival
Output ON signal when the running frequency of the
inverter is the lower limit frequency.
12
Ready
When the main circuit and the control circuit are
established and the protection function of the inverter
is not active. The inverter is in the running state and it
will output ON signal.
13
Pre-exciting
Output ON signal when the inverter is in the
pre-exciting state.
14
Overload pre-alarm
Output ON signal if the inverter is beyond the
pre-alarm point. Refer to P11.08~P11.10 for the
detailed instruction.
15
Underload pre-alarm
Output ON signal if the inverter is beyond the
pre-alarm point. Refer to P11.11~P11.12 for the
detailed instruction.
