INVT Goodrive 35 Series User Manual

Goodrive35 inverters Basic operation instruction
195
Function
code
Name
Detailed instruction of parameters
Default
value
synchronous motor 1
P02.17
Number of poles pairs for
synchronous motor 1
1~128
2
P02.18
Rated voltage of
synchronous motor 1
0~1200V
Depend
on model
P02.19
Rated current of
synchronous motor 1
0.8~6000.0A
Depend
on model
P02.20
Stator resistor of
synchronous motor 1
0.001~65.535Ω
Depend
on model
P02.21
Direct axis inductance of
synchronous motor 1
0.01~655.35mH
Depend
on model
P02.22
Quadrature axis
inductance of
synchronous motor 1
0.01~655.35mH
Depend
on model
P02.23
Back EMF constant of
synchronous motor 1
0~10000
300
P05.01~P0
5.09
Multi-function digital input
terminals
(S1~S8, HDI) function
selection
35: Shift from motor 1 to motor 2
P08.31
Motor shifting
0: Terminal shifting; digital terminal is 35
1: MODBUS communication shifting
2: PROFIBUS/CANopen communication
shifting
0
P12.00
Motor 2
0: Asynchronous motor
1: Synchronous motor
1
P12.01
Rated power of
asynchronous motor 2
0.1~3000.0kW
Depend
on model
P12.02
Rated frequency of
asynchronous motor 2
0.01Hz~P00.03(the Max. frequency)
50.00Hz
P12.03
Rated speed of
asynchronous motor 2
1~36000rpm
Depend
on model
P12.04
Rated voltage of
asynchronous motor 2
0~1200V
Depend
on model
