INVT Goodrive 35 Series User Manual

Goodrive35 inverters Product overview
16
Function
Specification
Analog input
2 (AI1, AI2) 0~10V/0~20mA and 1 (AI3) -10~10V
Analog output
2 (AO1, AO2) 0~10V /0~20mA
Digital input
8 common inputs, the Max. frequency: 1kHz,
internal impedance: 3.3kΩ;
1 high speed input, the Max. frequency: 50kHz
Digital output
1 high speed pulse output, the Max. frequency:
50kHz;
1 Y terminal open collector output
Relay output
2 programmable relay outputs
RO1A NO, RO1B NC, RO1C common terminal
RO2A NO, RO2B NC, RO2C common terminal
Contactor capability: 3A/AC250V,1A/DC30V
Spindle stopping
For spindle positioning and control sequence
Internal 7 scale marks and 4 zero marks
Position reference
External zero-position detection switch positioning
Encoder Z phase positioning
Servo control
Pulse train reference: position control
Frequency division
output
Encoder frequency division output
(H1 and H2 inverters)
Speed/position mode
Terminal shifting
Encoder
C1 support 100kHz, D1 support 500kHz, H1 support
300kHz and H2 support 400kHz
Positioning
Z pulse and photoelectric switch positioning
Others
Mountable method
Wall, flange and floor mountable
Temperature of the
running environment
-10~50℃, if temperature is above 40℃, derate 1%
for every additional 1℃.
Average non-fault
time
2 years (25℃ ambient temperature)
Protective degree
IP20
Cooling
Air-cooling
Braking unit
Built-in for inverters of 380V(≤30kW)
External for others
