INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Change history
No.
Change description
Version
Release date
1
First release.
V1.0
May 2021
2
 Added product data about the 1.5–22kW VFD
models.
 Added the description of the expansion card
EC-IO-503-00 in appendix A.4.
 Added appendix D.8 List of other optional
accessories.
 Corrected minor errors.
V1.1
April 2022
3
 Modified figures: Position of U-type short
connector in section 4.4.2 and External keypad
interface in section 4.5.
 Modified the function descriptions and figure in
section 5.5.12 Digital output.
 Modified some function codes in chapter 6.
 Updated communication card models to be
EC-TX503D, EC-TX505C and EC-TX509C
respectively in section A.5.
 Modified data of Table C-1–C-7 and updated
220–500kW dimension drawings in section C.4.
 Deleted contents of IP20 protection upgrade
assembly in section D.8.
V1.2
December
2022
4
 Modify model code and description in section 3.5.
 Modified 1.5kW–132kW VFD models and notes in
section 3.6, and updated VFD models in other
sections.
 Modified Figure 4-19 and Figure 4-41.
 Modified notes of sections 4.2.3 and 4.3.2.
 Modified the keypad description in sections 5.2
and 5.3, and added the LCD keypad display and
operation in section 5.4.
 Modified Figure 5-29, and added Figure 5-30 and
Figure 5-31 in section 5.5.16.
 Modified the function parameter list in section 6.2,
and updated other function parameters in other
sections.
 Deleted the command code 08H from section 9.4.
 Deleted the indicator definition contents from
V1.3
August 2023

INVT Goodrive270 Series Specifications

General

Brand	INVT
Model	Goodrive270 Series
Category	Water Pump
Language	English
