INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-179-
Function
code
Name
Description
Default
Modify
for switching off IF
mode for AM 2
P04.52
VF energy-saving
mode selection
0: Max. efficiency
1: Optimal power factor
2: MTPA
0
○
P04.53
Energy-saving gain
coefficient
0.0%–400.0%
100.0
○
P04.54
Angle
compensation
coefficient in energy
saving control
40.0%–200.0%
Note: A small value of this parameter increases
energy saving control effect, but this also
reduces the load carrying capability for sudden
load.
80.0%
○
P05 group––Input terminals
Function
code
Name
Description
Default
Modify
P05.00
HDI input type
0x00–0x11
Ones place: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens place: Reserved
0x00
◎
P05.01
Function of S1
0: No function
1: Run forward
2: Run reversely
3: Three-wire running control
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
9: External fault input
10: Increase frequency setting (UP)
11: Decrease frequency setting (DOWN)
12: Clear the frequency increase/decrease setting
13: Switch between A setting and B setting
14: Switch between combination setting and A
setting
15: Switch between combination setting and B
1
◎
P05.02
Function of S2
4
◎
P05.03
Function of S3
7
◎
P05.04
Function of S4
(choose one of
S4 and Y1
output)
0
◎
