INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-178-
Function
code
Name
Description
Default
Modify
current of the motor.
Setting range: 0.0–200.0%
P04.42
Proportional
coefficient in IF
mode for AM 1
When IF control is adopted for AM 1, the
function code is used to set the proportional
coefficient of the output current closed-loop
control.
Setting range: 0–5000
350
○
P04.43
Integral coefficient
in IF mode for AM 1
When IF control is adopted for AM 1, the
function code is used to set the integral
coefficient of the output current closed-loop
control.
Setting range: 0–5000
150
○
P04.44
Starting frequency
point for switching
off IF mode for AM 1
0.00–P04.50
10.00Hz
○
P04.45
Enabling IF mode
for AM 2
0: Invalid
1: Enable
0
◎
P04.46
Current setting in IF
mode for AM 2
When IF control is adopted for AM 2, the
function code is used to set the output current.
The value is a percentage in relative to the rated
current of the motor.
Setting range: 0.0–200.0%
120.0%
○
P04.47
Proportional
coefficient in IF
mode for AM 2
When IF control is adopted for AM 2, the
function code is used to set the proportional
coefficient of output current closed-loop control.
Setting range: 0–5000
350
○
P04.48
Integral coefficient
in IF mode for AM 2
When IF control is adopted for AM 2, the
function code is used to set the integral
coefficient of output current closed-loop control.
Setting range: 0–5000
150
○
P04.49
Starting frequency
point for switching
off IF mode for AM 2
0.00–P04.51
10.00Hz
○
P04.50
End frequency point
for switching off IF
mode for AM 1
P04.44–P00.03
25.00Hz
○
P04.51
End frequency point
P04.49–P00.03
25.00Hz
○
