INVT Goodrive270 Series

Goodrive270 series VFD for fan and pump Energy efficiency data
-359-
Appendix E Energy efficiency data
Table E–1 Power loss and IE class
Model
Relative loss (%)
Stand
by
loss
(W)
IE
class
(0;25)
(0;50)
(0;10
0)
(50;25)
(50;50)
(50;100)
(90;50)
(90;100)
GD270-1R5-4(-C2)
0.78
0.95
1.03
0.86
1.17
1.23
1.35
2.02
13
IE2
GD270-2R2-4(-C2)
0.82
0.76
0.55
1.09
1.11
1.07
1.59
1.76
17
IE2
GD270-004-4(-C2)
0.74
1.20
1.55
1.15
1.28
1.89
1.45
2.29
16
IE2
GD270-5R5-4(-C2)
0.71
0.97
1.32
1.02
1.21
1.83
1.34
2.18
17
IE2
GD270-7R5-4(-C2)
0.68
0.78
1.75
0.76
1.03
1.79
1.22
2.06
20
IE2
GD270-011-4(-L1/-C2)
0.65
0.89
1.62
0.66
1.37
1.43
1.38
2.28
27
IE2
GD270-015-4(-L1/-C2)
0.96
1.30
2.26
0.74
0.90
1.43
0.87
1.49
27
IE2
GD270-018-4(-L1/-C2)
0.72
0.95
1.57
1.20
1.46
2.17
1.47
2.26
30
IE2
GD270-022-4(-L1/-C2)
0.67
0.87
1.44
1.07
1.29
1.92
1.27
2.04
30
IE2
GD270-030-4(-L1)(-C3)
0.71
0.98
1.76
1.22
1.89
2.42
2.17
2.83
30
IE2
GD270-037-4(-L1)(-C3)
0.67
0.85
1.60
1.09
1.75
2.37
1.91
2.73
30
IE2
GD270-045-4(-L1)(-C3)
0.47
0.62
1.14
1.09
1.27
1.90
1.52
2.02
30
IE2
GD270-055-4(-L1)(-C3)
0.42
0.69
1.04
0.98
1.19
1.72
1.45
1.88
31
IE2
GD270-075-4(-L1)(-C3)
0.52
0.80
1.35
1.06
1.42
2.10
1.67
2.23
32
IE2
GD270-090-4(-L1)(-C3)
0.40
0.72
1.29
0.93
1.31
1.98
1.58
2.11
31
IE2
GD270-110-4(-L1)(-C3)
0.42
0.69
1.20
0.84
0.98
1.67
1.27
1.72
33
IE2
GD270-132-4(-L1)(-C3)
0.50
0.65
1.28
0.97
1.12
1.74
1.22
1.85
35
IE2
GD270-160-4(-L1)
0.61
1.01
1.52
1.37
1.32
2.02
1.42
2.14
37
IE2
GD270-185-4(-L1)
0.56
0.95
1.45
1.13
1.19
1.88
1.37
2.07
37
IE2
GD270-200-4(-L1)
0.48
0.81
1.33
0.99
1.08
1.78
1.28
1.99
38
IE2
GD270-220-4(-Ln)
0.59
0.85
1.76
1.24
1.58
2.61
1.68
2.65
40
IE2
GD270-250-4(-Ln)
0.65
0.91
1.86
1.33
1.72
2.79
1.73
2.85
42
IE2
GD270-280-4(-Ln)
0.68
0.98
1.92
1.27
1.61
2.54
1.62
2.69
48
IE2
GD270-315-4(-Ln)
0.66
0.94
1.88
1.19
1.49
2.45
1.56
2.54
50
IE2
GD270-355-4(-Ln)
0.72
1.01
1.87
1.11
1.37
2.30
1.47
2.47
52
IE2
GD270-400-4-Ln
0.78
0.82
1.64
1.14
1.38
2.25
1.43
2.31
55
IE2
GD270-450-4-Ln
0.75
0.89
1.52
1.08
1.27
2.16
1.37
2.23
58
IE2
GD270-500-4-Ln
0.73
0.78
1.40
0.90
1.10
1.90
1.25
2.16
60
IE2
Note: n = 1 or 3
