Goodrive270 series VFD for fan and pump Function parameter list
-241-
Function
code
Name
Description
Default
Modify
P23.14 setting range: 0.0100.0% (of the max.
frequency)
P25 group––Input functions of expansion I/O card
Function
code
Name
Description
Default
Modify
P25.00
Reserved
P25.01
Function of S5
Same as P05
0
P25.02
Function of S6
0
P25.03
Function of S7
0
P25.04
Function of S8
0
P25.05
Function of S9
0
P25.06
Function of S10
0
P25.07
Reserved
0
P25.08
Expansion card
input terminal
polarity
0x000x7F
0x00
P25.09
Expansion card
virtual terminal
setting
0x0000x7F (0: Disable. 1: Enable)
BIT0: S5 virtual terminal
BIT1: S6 virtual terminal
BIT2: S7 virtual terminal
BIT3: S8 virtual terminal
BIT4: S9 virtual terminal
BIT5: S10 virtual terminal
BIT6: Reserved
0x00
P25.10
Reserved
Used to specify the delay time corresponding to
the electrical level changes when the
programmable input terminals switch on or
switch off.
Si electrical level
Si valid
invalid invalid
Switch-on
delay
Switch-off
delay
valid
Setting range: 0.00050.000s
0.000s
P25.11
Reserved
0.000s
P25.12
S5 switch-on delay
0.000s
P25.13
S5 switch-off delay
0.000s
P25.14
S6 switch-on delay
0.000s
P25.15
S6 switch-off delay
0.000s
P25.16
S7 switch-on delay
0.000s
P25.17
S7 switch-off delay
0.000s
P25.18
S8 switch-on delay
0.000s
P25.19
S8 switch-off delay
0.000s
P25.20
S9 switch-on delay
0.000s
P25.21
S9 switch-off delay
0.000s
