INVT Goodrive270 Series

Goodrive270 series VFD for fan and pump Expansion card
-315-
Appendix A Expansion card
A.1 Model definition
EC-TX 5 03-05 B
① ② ③ ④ ⑤
⑥
Field
Field description
Naming example
Remarks
①
Product category
EC: Expansion card
②
Card category
TX: communication card
IO: I/O card
③
Version category
Indicates the generation of a version
category by using odd numbers, for
example, 1, 3, 5, and 7 indicate the 1st,
2nd, 3rd and 4th generations of
version.
④
Product code
(communication
card)
01: Bluetooth card
02: WiFi card
03: PROFIBUS-DP
04: Ethernet communication card
05: CANopen communication card
06: Reserved
07: BACnet communication card
08: Reserved
09: PROFINET communication card
10: Reserved
11: CAN master/slave control
communication card
12: MECHATROLINK communication
card
13: MEMOBUS communication card
14: CC- LINK communication card
15: Modbus TCP communication card
16: CC-LINK IE communication card
17: POWERLINK communication card
18: Reserved 1
19: Reserved 2
The value options increase
by 1 in sequence, starting
from 01. The naming
relationship depends on the
board category.
