INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Product overview
-12-
Field
No.
Field description
Content
1.5-132kW
C2: with built-in C2 filter, applicable to 1.5–22kW
models
C3: with built-in C3 filter, applicable to 30–132kW
models
3.6 Product ratings
Table 3-1 Ratings for AC 3PH 380V models
VFD model
Output power
(kW)
Input current (A)
Output current
(A)
GD270-1R5-4(-C2)
1.5
5 (5)
3.7
GD270-2R2-4(-C2)
2.2
6 (6)
5
GD270-004-4(-C2)
4
15 (15)
9.5
GD270-5R5-4(-C2)
5.5
20 (20)
13
GD270-7R5-4(-C2)
7.5
27 (27)
17
GD270-011-4(-L1/-C2)
11
35 (35)
25
GD270-015-4(-L1/-C2)
15
44 (44)
32
GD270-018-4(-L1/-C2)
18
46 (46)
38
GD270-022-4(-L1/-C2)
22
54 (54)
45
GD270-030-4(-L1)(-C3)
30
75 (56)
60
GD270-037-4(-L1)(-C3)
37
90 (69)
75
GD270-045-4(-L1)(-C3)
45
108 (101)
92
GD270-055-4(-L1)(-C3)
55
142 (117)
115
GD270-075-4(-L1)(-C3)
75
177 (149)
150
GD270-090-4(-L1)(-C3)
90
200 (171)
180
GD270-110-4(-L1)(-C3)
110
240 (205)
215
GD270-132-4(-L1)(-C3)
132
278 (235)
250
GD270-160-4(-L1)
160
310 (296)
305
GD270-185-4(-L1)
185
335 (320)
330
GD270-200-4(-L1)
200
385 (368)
380
GD270-220-4(-Ln)
220
430 (411)
425
GD270-250-4(-Ln)
250
465 (444)
460
GD270-280-4(-Ln)
280
540 (485)
530
GD270-315-4(-Ln)
315
605 (550)
600
GD270-355-4(-Ln)
355
655 (600)
650
GD270-400-4-Ln
400
660
720
GD270-450-4-Ln
450
745
820
GD270-500-4-Ln
500
800
860
