INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-95-
Function
code
Name
Description
Default
P08.02
ACC time 3
0.0–3600.0s
Depends
on model
P08.03
DEC time 3
0.0–3600.0s
Depends
on model
P08.04
ACC time 4
0.0–3600.0s
Depends
on model
P08.05
DEC time 4
0.0–3600.0s
Depends
on model
P08.06
Running frequency of jog
0.00Hz–P00.03(Max. output frequency)
5.00Hz
P08.07
ACC time for jogging
0.0–3600.0s
Depends
on model
P08.08
DEC time for jogging
0.0–3600.0s
Depends
on model
P08.19
Switching frequency of
ACC/DEC time
0.00–P00.03(Max. frequency)
0.00Hz: No switchover
If the running frequency is greater than
P08.19, switch to ACC/DEC time 2.
0
P08.21
Reference frequency of
ACC/DEC time
0: Max. output frequency
1: Set frequency
2: 100Hz
Note: Valid only for straight-line ACC/DEC
0
P08.28
Auto fault reset count
0–10
0
P08.29
Auto fault reset interval
0.1–3600.0s
1.0s
5.5.8 Frequency setting
The VFD supports multiple kinds of frequency reference modes, which can be categorized into two
types: main reference channel and auxiliary reference channel.
There are two main reference channels, namely frequency reference channel A and frequency
reference channel B. These two channels support simple arithmetical operation between each other,
and they can be switched dynamically by setting multifunction terminals.
There is one input mode for auxiliary reference channel, namely terminal UP/DOWN switch input. By
setting function codes, you can enable the corresponding reference mode and the impact made on
the VFD frequency reference by this reference mode.
The VFD actual reference is comprised of the main reference channel and auxiliary reference
channel.
