INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-94-
Function
code
Name
Description
Default
P01.21
Power-off restart selection
0: Disable
1: Enable
0
P01.22
Wait time for restart after
power-off
0.0–3600.0s (valid when P01.21 is 1)
1.0s
P01.23
Start delay
0.0–60.0s
0.0s
P01.24
Stop speed delay
0.0–100.0s
0.0s
P01.25
Open-loop 0Hz output
selection
0: Output without voltage
1: Output with voltage
2: Output with the DC braking current for
stop
0
P01.26
DEC time for emergency
stop
0.0–60.0s
2.0s
P01.27
Time of starting segment of
DEC S curve
0.0–50.0s
0.1s
P01.28
Time of ending segment of
DEC S curve
0.0–50.0s
0.1s
P01.29
Short-circuit braking current
0.0–150.0% (of the VFD rated current)
0.0%
P01.30
Hold time of short-circuit
braking for start
0.00–50.00s
0.00s
P01.31
Hold time of short-circuit
braking for stop
0.00–50.00s
0.00s
P01.32
Pre-exciting time for jogging
0–10.000s
0.300s
P01.33
Starting frequency of
braking for stop in jogging
0.00–P00.03
0.00Hz
P01.34
Sleep delay
0–3600.0s
0.0s
P05.01–
P05.06
Digital input function
selection
1: Run forward
2: Run reversely
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
21: ACC/DEC time selection 1
22: ACC/DEC time selection 2
30: Disable ACC/DEC
P08.00
ACC time 2
0.0–3600.0s
Depends
on model
P08.01
DEC time 2
0.0–3600.0s
Depends
on model
