INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-93-
Function
code
Name
Description
Default
For AMs, you do not need to modify
parameters P01.35–P01.41.
P01.01
Starting frequency of direct
start
0.00–50.00Hz
0.50Hz
P01.02
Starting frequency hold time
0.0–50.0s
0.0s
P01.03
Braking current before start
0.0–100.0%
0.0%
P01.04
DC braking time before start
0.00–50.00s
0.00s
P01.05
ACC/DEC mode
0: Linear
1: S curve
Note: If mode 1 is selected, set P01.06,
P01.07, P01.27 and P01.28.
0
P01.08
Stop mode
0: Decelerate to stop
1: Coast to stop
0
P01.09
Starting frequency of DC
braking for stop
0.00Hz–P00.03(Max. output frequency)
0.00Hz
P01.10
Wait time before DC braking
for stop
0.00–50.00s
0.00s
P01.11
DC braking current for stop
0.0–100.0%
0.0%
P01.12
DC braking time for stop
0.00–50.00s
0.00s
P01.13
FWD/REV running
deadzone time
0.0–3600.0s
0.0s
P01.14
FWD/REV running
switching mode
0: Switch at zero frequency
1: Switch at the starting frequency
2: Switch after the speed reaches the stop
speed with a delay
0
P01.15
Stop speed
0.00–100.00Hz
0.50 Hz
P01.16
Stop speed detection mode
0: Detect by the set speed (unique in
space voltage vector control mode)
1: Detect by the feedback speed
1
P01.18
Terminal-based running
command protection at
power-on
0: The terminal running command is
invalid at power-on
1: The terminal running command is valid
at power-on
0
P01.19
Action selected when
running frequency less than
frequency lower limit (valid
when frequency lower limit
greater than 0)
0: Run at the frequency lower limit
1: Stop
2: Sleep
0
P01.20
Wake-up-from-sleep delay
0.0–3600.0s (valid when P01.19 is 2)
0.0s
