Goodrive270 series VFD for fan and pump Function parameter list
-177-
Function
code
Name
Description
Default
Modify
Setting range: -100.0%–+100.0% (of the motor
rated current)
P04.35
Pull-in current 2 in
SM V/F control
When the SM VF control mode is enabled, the
function code is used to set the reactive current
of the motor when the output frequency is higher
than the frequency specified by P04.36.
Setting range: -100.0%–+100.0% (of the motor
rated current)
10.0%
â—‹
P04.36
Frequency
threshold for pull-in
current switching in
SM V/F control
When the SM V/F control mode is enabled, the
function code is used to set the frequency
threshold for the switching between pull-in
current 1 and pull-in current 2.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
50.00Hz
â—‹
P04.37
Reactive current
closed-loop
proportional
coefficient in SM
V/F control
When the SM V/F control mode is enabled, the
function code is used to set the proportional
coefficient of reactive current closed-loop
control.
Setting range: 0–3000
50
â—‹
P04.38
Reactive current
closed-loop integral
time in SM V/F
control
When the SM V/F control mode is enabled, the
function code is used to set the integral
coefficient of reactive current closed-loop
control.
Setting range: 0–3000
30
â—‹
P04.39
Reactive current
closed-loop output
limit in SM VF
control
When the SM V/F control mode is enabled, the
function code is used to set the output limit of
the reactive current closed-loop control. A
greater value indicates a higher reactive
closed-loop compensation voltage and higher
output power of the motor. In general, you do
not need to modify the function code.
Setting range: 0–16000
8000
â—‹
P04.40
Enabling IF mode
for AM 1
0: Invalid
1: Enable
0
â—Ž
P04.41
Current setting in IF
mode for AM 1
When IF control is adopted for AM 1, the
function code is used to set the output current.
The value is a percentage in relative to the rated
120.0%
â—‹
