INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Optional peripheral accessories
-356-
Model
Rated power (kW)
Rated input current (A)
Filter model
GD270-045-4-L1
45
101
FN 3258-100-35
GD270-055-4-L1
55
117
FN 3258-130-35
GD270-075-4-L1
75
149
FN 3258-180-40
GD270-090-4-L1
90
171
FN 3258-180-40
GD270-110-4-L1
110
205
FN 3359-250-28
GD270-132-4-L1
132
235
FN 3359-250-28
D.7.1.2 FLT input filters
Choose the filters in the following table to meet the C2 EMC requirements under the condition of 1m
motor cable.
Table D-7 FLT input filter model selection for AC 3PH 380V VFDs
VFD model
Input filter
GD270-1R5-4
FLT-P04006L-B
GD270-2R2-4
GD270-004-4
FLT-P04016L-B
GD270-5R5-4
FLT-P04032L-B
GD270-7R5-4
GD270-011-4(-L1)
FLT-P04045L-B
GD270-015-4(-L1)
GD270-018-4(-L1)
FLT-P04065L-B
GD270-022-4(-L1)
GD270-030-4(-L1)
FLT-P04100L-B
(FLT-P04065L-B)
GD270-037-4(-L1)
FLT-P04100L-B
GD270-045-4(-L1)
GD270-055-4(-L1)
FLT-P04150L-B
GD270-075-4(-L1)
FLT-P04240L-B
(FLT-P04150L-B)
GD270-090-4(-L1)
FLT-P04240L-B
GD270-110-4(-L1)
GD270-132-4(-L1)
FLT-P04400L-B
GD270-160-4(-L1)
GD270-185-4(-L1)
GD270-200-4(-L1)
GD270-220-4(-Ln)
FLT-P04600L-B
GD270-250-4(-Ln)
GD270-280-4(-Ln)
