Goodrive35 Series Closed-loop Vector Control VFD Function parameters
48
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
Note: Max. output frequency ≥ Upper limit frequency
≥ Lower limit frequency
Setting range: 0.00 HzP00.04 (Upper limit of the
running frequency)
P00.06
A frequency
command
Note: Frequency A and frequency B cannot use the
same frequency setting mode. The frequency source
can be set by P00.09.
0: Keypad
Modify the value P00.10 (set the frequency by
keypad) to modify the frequency by the keypad.
1: AI1
2: AI2
3: AI3
Set the frequency by analog input terminals.
Goodrive35 series VFDs provide 3 analog input
terminals as the standard configuration, of which
AI1/AI2 are the voltage/current option (010
V/020mA) which can be shifted by jumpers; while
AI3 is voltage input (-10 V+10 V).
Note: When AI1/AI2 select 020mA input, the
corresponding voltage of 20mA is 10 V.
100.0% of the analog input setting corresponds to
the maximum frequency (function code P00.03) in
forward direction and -100.0% corresponds to the
maximum frequency in reverse direction (function
code P00.03)
4: High-speed pulse HDI setting
The frequency is set by high-speed pulse terminals.
Goodrive35 series VFDs provide 1 high speed pulse
input as the standard configuration. The pulse
frequency range is 0.0050.00 kHz.
100.0% of the high speed pulse input setting
corresponds to the maximum frequency in forward
direction (P00.03) and -100.0% corresponds to the
maximum frequency in reverse direction (P00.03).
Note: The pulse setting can only be input by
multi-function terminals HDI. Set P05.00 (HDI input
selection) to high speed pulse input, and set P05.49
0
P00.07
B frequency
command
2
