Goodrive35 Series Closed-loop Vector Control VFD Function parameters
79
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
The setting range of P05.37: 0.00 V–P05.39
The setting range of P05.38: -300.0%–300.0%
The setting range of P05.39: P05.37–10.00 V
The setting range of P05.40: -300.0%–300.0%
The setting range of P05.41: 0.000s–10.000s
The setting range of P05.42: -10.00 V–P05.44
The setting range of P05.43: -300.0%–300.0%
The setting range of P05.44: P05.42–P05.46
The setting range of P05.45: 0.00–10.00 V
The setting range of P05.46: P05.44–10.00 V
The setting range of P05.47: -300.0%–300.0%
The setting range of P05.48: 0.000s–10.000s
P05.49
HDI high-speed
pulse input function
The function selection when HDI terminals is
high-speed pulse input
0: Frequency setting input, frequency setting source
1–2: Reserved
0
◎
P05.50
Lower limit frequency
of HDI
0.000 kHz–P05.52
0.000
kHz
○
P05.51
Corresponding
setting of HDI low
frequency
-300.0%–300.0%
0.0%
○
P05.52
Upper limit frequency
of HDI
P05.50–50.000 kHz
50.000
kHz
○
P05.53
Corresponding
setting of upper limit
frequency of HDI
-300.0%–300.0%
100.0%
○
P05.54
HDI frequency input
filter time
0.000s–10.000s
0.030s
○
P06 Group Output terminals
P06.00
HDO output
The function selection of the high-speed pulse
output terminals.
0: Open collector pole high speed pulse output: The
Max pulse frequency is 50.0 kHz. See
P06.27–P06.31 for detailed information of the
related functions.
1: Open collector pole output. See P06.02 for
detailed information of the related functions.
0
◎
