INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Function parameters
59
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
performance, configure
the motor based on the
motor which matches with
the VFD. If the gap
between motor power and
the matched motor is too
large, the control
performance of the VFD
will be deteriorated
greatly.
Note: P02.02–P02.10
can be initialized by
resetting rated motor
power P02.01.
P02.06
Stator resistor of AM
1
0.001–65.535Ω
After motor parameter
autotuning finishes, the
setting value of
P02.06–P02.10 will be
updated automatically.
These parameters are the
basic parameters for
high-performance vector
control, which will impact
the control performance
directly.
Note: Users cannot
change this group of
parameters at will.
Depend
on model
○
P02.07
Rotor resistor of AM
1
0.001–65.535Ω
Depend
on model
○
P02.08
Leakage inductance
of AM 1
0.1–6553.5mH
Depend
on model
○
P02.09
Mutual inductance of
AM 1
0.1–6553.5mH
Depend
on model
○
P02.10
Non-load current of
AM 1
0.1–6553.5A
Depend
on model
○
P02.11
Magnetic saturation
coefficient 1 for iron
core of AM1
0.0–100.0%
80.0%
◎
P02.12
Magnetic saturation
coefficient 2 for iron
core of AM1
0.0–100.0%
68.0%
◎
P02.13
Magnetic saturation
coefficient 3 for iron
core of AM1
0.0–100.0%
55.0%
◎
P02.14
Magnetic saturation
0.0–100.0%
40.0%
◎
