Goodrive35 Series Closed-loop Vector Control VFD Function parameters
60
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
coefficient 4 for iron
core of AM1
P02.15
Rated power of SM 1
0.1–3000.0 kW
Set the parameters of
controlled SM.
In order to ensure control
performance, set the
value of P02.15–P02.19
based on the nameplate
parameters of the motor.
Goodrive35 series VFD
provides parameter
autotuning function. The
accurate parameter
autotuning requires
proper parameter setup.
In order to ensure control
performance, configure
the motor based on the
motor which matches with
the VFD. If the gap
between motor power and
the matching motor is too
large, the control
performance of the VFD
will be deteriorated
greatly.
Note: P02.16–P02.19
can be initialized by
resetting rated motor
power P02.15.
Depend
on model
◎
P02.16
Rated frequency of
SM 1
0.01 Hz–P00.03 (max.
output frequency)
50.00
Hz
◎
P02.17
Number of poles
pairs for SM 1
1–128
2
◎
P02.18
Rated voltage of SM
1
0–1200 V
Depend
on model
◎
P02.19
Rated current of SM
1
0.8–6000.0 A
Depend
on model
◎
P02.20
Stator resistor of SM
1
0.001–65.535 Ω
After motor parameter
autotuning finishes, the
set value of
P02.20–P02.22 will be
updated automatically.
These parameters are the
basic parameters for high
performance vector
Depend
on model
○
P02.21
Direct axis
inductance of SM 1
0.01–6553.5 mH
Depend
on model
○
P02.22
Quadrature axis
inductance of SM 1
0.01–655.35 mH
Depend
on model
○
P02.23
Back EMF constant
of SM 1
When P00.15=2, the set
value of P02.23 cannot be
320
○
