PASCAL
®
Synthesis Ophthalmic Scanning Laser Systems Page 116 of 141
88292-EN, Rev D
Code
Message
Critical
Clearable
Warning
Description
Action
50
Treatment LBO
Temperature Over
Maximum
X
OPSL LBO Temperature during
treatment exceeds
Laser module maximum
allowable value
Allow system to cool.
Reconfigure treatment
parameters if
necessary
51
Treatment
Temperature Over
Maximum (Red Laser
modules)
X
Red Laser modules Base
Temperature during treatment
exceeds
Laser module maximum
allowable value
Allow system to cool.
Reconfigure treatment
parameters if
necessary
52
Ambient
Temperature Over
Maximum
X
Ambient Temperature during
treatment exceeds maximum
allowable value
Allow system to cool.
Reconfigure treatment
parameters if
necessary
56
Aiming Local Light
Over (High)
X
Aiming laser output is 100% over
the expected value
User to select End
Treatment and Return to
the Home Screen.
Re-access treatment screen
and reconfigure treatment
parameters.
If error repeats- End
Treatment and call Service
57
OPSL Treatment
Local Light Under
(Low)
X
Laser output is 20% under the
expected value
User to select End
Treatment and Return to
the Home Screen.
Re-access treatment screen
and reconfigure treatment
parameters.
If error repeats- End
Treatment and call Service
58
OPSL Treatment
Local Light Over
(Low)
X
Laser output is 20% over the
expected value
User to select End
Treatment and Return to
the Home Screen.
Re-access treatment screen
and reconfigure treatment
parameters.
If error repeats- End
Treatment and call Service
59
OPSL Treatment
Local Light Over
(Medium)
X
Laser output is 50% over the
expected value
User to select End
Treatment and Return to
the Home Screen.
Re-access treatment
screen and reconfigure
treatment parameters.
If error repeats- End
Treatment and call Service
60
OPSL Treatment
Local Light Over
(High)
X
Laser output is 100% over the
expected value
User to select End
Treatment and Return to
the Home Screen.
Re-access treatment screen
and reconfigure treatment
parameters.
If error repeats- End
Treatment and call Service
