PASCAL
®
Synthesis Ophthalmic Scanning Laser Systems Page 118 of 141
88292-EN, Rev D
Code
Message
Critical
Clearable
Warning
Description
Action
Re-access treatment screen
and reconfigure treatment
parameters. If error repeats-
End Treatment and call
Service
69
Unexpected local
light (OPSL Aiming)
X
Laser output was detected when it
was not expected
Verify device connections.
70
Unexpected local
light (Red 60µm)
X
Laser output was detected when it
was not expected
Verify device connections.
71
Unexpected local
light (Red 200µm)
X
Laser output was detected when it
was not expected
Verify device connections.
72
X-Galvo Spot
Position Service
Error During Aiming
X
An error occurred within the spot
position service regarding the X
galvo during aiming beam output
Clear error to continue.
Call service if error persists.
73
Y-Galvo Spot
Position Service
Error During Aiming
X
An error occurred within the spot
position service regarding the Y
galvo during aiming beam output
Clear error to continue.
Call service if error persists.
74
X-Galvo Spot
Position Service
Error During
Treatment
X
An error occurred within the spot
position service regarding the X
galvo during treatment output
Clear error to continue.
Call service if error persists.
75
Y-Galvo Spot
Position Service
Error During
Treatment
X
An error occurred within the spot
position service regarding the Y
galvo during treatment output
Clear error to continue.
Call service if error persists.
76
Spot Size Service F-
Galvo
X
An error occurred within the spot
size service regarding the F galvo
Clear error to continue
Call service if error persists.
77
Software Watchdog
X
Main PCB controller has been reset
or did not synchronize with the
SBC.
Reboot.
Call service if error persists.
78
Host Communication
X
Communication with the SBC
failed.
Reboot.
Call service if error persists.
79
Port 1 Fault
X
An error was detected with port 1
Reboot.
Call service if error persists.
80
Port 2 Fault
X
An error was detected with port 2
Reboot.
Call service if error persists
91
Footswitch
Discrepancy
X
Defective Footswitch connected
Verify footswitch connection.
92
Main DSP
Communication
X
Communication with the Main DSP
failed.
Call service if error persists.
93
Galvo DSP
Communication
X
Communication with the Galvo DSP
failed.
Call service if error persists.
108
Firmware Revision
Request
X
The Main PCB cannot provide the
firmware revision
Call service if error persists.
128
Application
Configuration
X
The firmware failed to accept the
application configuration
Call service if error persists.
129
System
Configuration
X
The firmware failed to accept the
system configuration
Call service if error persists.
132
Set Audio
X
The firmware failed to enable or
disable the audio
Call service if error persists.
204
Touchscreen Error
X
The Touchscreen was
disconnected.
Reboot. Check connections.
Call service if error persists.
205
Kill Line Asserted
X
The front-end DIO determined that
the kill lines were asserted.
Reboot.
Call service if error persists.
