PASCAL
®
Synthesis Ophthalmic Scanning Laser Systems Page 119 of 141
88292-EN, Rev D
Code
Message
Critical
Clearable
Warning
Description
Action
206
SLA Detached
X
The SLA is not attached
Verify connection to
slit lamp.
207
Pattern Locked
X
The pattern cannot be modified at
this time. Certain patterns can only
be modified in Standby mode.
Press Ready button on
Touchscreen to return
to Standby mode before
modifying patterns.
208
System Busy
X
The user cannot start a treatment
because the system has a pending
message.
User to select End
Treatment and Return to
the Home Screen.
Re-access treatment screen
and reconfigure treatment
parameters.
If error repeats- End
Treatment and call Service
209
Footswitch in
Standby
X
The user pressed the footswitch in
standby mode.
Press Standby button on
Touchscreen to enter
Ready mode.
210
No output available
X
The user cannot become Ready
because the SLA is detached and
all external ports are empty.
Check SLA
connection. Reboot.
Call service if error persists.
211
Must use LIO
X
The user cannot deselect the
currently selected LIO because the
SLA is not attached.
Check LIO or SLA
connection.
Reboot.
Call service if error persists.
212
Attachment CRC
Error
X
The 1-wire data on an attachment
(LIO or SLA) has an invalid CRC
value.
Check LIO or SLA
connection.
Reboot.
Call service if error persists.
213
Laser Color
Mismatch
X
The 1-wire data on an attachment
(LIO or SLA) says that the device
does not support the system laser’s
color
Check LIO or SLA
connection.
Reboot.
Call service if error persists.
214
Bad Attachment
Version
X
The 1-wire data on an attachment
(LIO or SLA) has an unsupported
format version.
Check LIO or SLA
connection.
Reboot.
Call service if error persists.
215
Cannot Load
Favorite: Not Single
Spot
X
The system cannot load the
selected favorite because the SLA
is not attached, and the favorite is
not for the single-spot pattern.
Select a different favorite
or set parameters using the
Touchscreen.
216
Cannot Load
Favorite: No Output
X
The system cannot load the favorite
because no attachments (LIO or
SLA) are attached.
Select a different favorite
or set parameters using the
Touchscreen or attach an
LIO or SLA.
217
Cannot Load
Favorite: No LIO
X
The system cannot load the favorite
because it requires an LIO but no
LIO is attached
Select a different favorite
or set parameters using the
Touchscreen or attach an
LIO.
218
Cannot Load
Favorite: Bad
Pattern
X
The system cannot load the favorite
because it refers to a pattern that is
not in the system.
Select a different favorite
or set parameters using the
Touchscreen.
219
Database Error
X
The system cannot function
because a database operation
returned an error code.
Reboot.
Call service if error persists.
220
Laser Warmup
Timeout
X
The back-end could not warm the
lasers up quickly enough.
Reboot.
Call service if error persists.
221
3D Controller Error
X
The 3D controller is disconnected
or there was an error attempting to
Unplug and plug in the 3D
controller USB connector
