Enhanced Octants
Primary pattern
Secondary pattern
10ms New PC
Octants
(Enhanced
Octants)
Not available
General Use
Pattern
Spot
Diameter
Spacing
Radius
(Inner
radius)
Radius
(Outer
radius)
EPM %
Enhanced Octants
100μm
0.00Ø
500µm to
2000µm
700µm to
2200µm
10 to 95
0.25Ø to
1.00Ø
500µm to
1900µm
800µm to
2200µm
1.50Ø to
2.00Ø
500µm to
1800µm
900µm to
2200µm
2.50Ø to
3.00Ø
500µm to
1700µm
1000µm to
2200µm
200μm
0.00Ø
500µm to
1800µm
900µm to
2200µm
0.25Ø to
0.50Ø
500µm to
1700µm
1000µm to
2200µm
1.00Ø
500µm to
1600µm
1100µm to
2200µm
To select a number of octants, drag your finger around the Octants pattern.
NOTE
• The selection of inner radius and outer radius will differ depending on slit lamp used.
• The full range of settings is not available for every combination of parameters.
Auto Advance Feature
If the Auto Advance feature is enabled, one segment of Octants pattern is delivered when
you depress the footswitch, after which the system automatically advances to the next
segment of Octants pattern selected. After the last segment of Octants pattern is delivered,
the system returns to the initial subset of Octants when Auto-Transition feature is set to No
Transition.
