ise smart connect KNX Sonos
Configuration
Order No. 1-0001-002
Product Manual Page 33 (76)
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
8 (group 1)
108 (group 2)
208 (group 3)
308 (group 4)
408 (group 5)
Volume state
Read
1 byte
5.001
CR-T-
Rubric:
Volume
Data type:
Percent (0 to 100%)
Function:
Group 1/2/3/4/5 – Current volume
Description:
Supplies the volume value over the bus: 0 corresponds to 0%, and 255 to
100% volume
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
9 (group 1)
109 (group 2)
209 (group 3)
309 (group 4)
409 (group 5)
Relative volume control
Write
4 bit
3.007
C-W--
Rubric:
Volume
Data type:
Dimmer step
Function:
Group 1/2/3/4/5 – Turn volume up or down
Description:
Enables louder or quieter relative volume adjustment over the bus. Suitable
transmitters include push button sensors with the "Brighten/Dim" function, for
example
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
10 (group 1)
110 (group 2)
210 (group 3)
310 (group 4)
410 (group 5)
Volume up/down
Write
1 bit
1.007
C-W--
Rubric:
Volume
Data type:
Step
Function:
Group 1/2/3/4/5 – Turn volume up or down by 5%
Description:
Enables relative volume adjustment louder/quieter in increments up to 5% via
1-bit group telegrams: 1 = 5% louder, 0 = 5% quieter.
