ISE Sonos - Page 41

ise smart connect KNX Sonos
Configuration
Order No. 1-0001-002
Product Manual Page 41 (76)
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
35 (group 1)
135 (group 2)
235 (group 2)
335 (group 3)
435 (group 4)
Group volume control
up/down
Write
1 bit
1.007
C-W--
Rubric:
Group volume
Data type:
Step
Function:
Group 1/2/3/4/5 – Turn group volume up or down by 5%
Description:
Enables relative adjustment (louder/quieter) of the group volume in increments
up to 5% via 1-bit group telegrams: 1 = 5% louder, 0 = 5% quieter.
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
36 (group 1)
136 (group 2)
236 (group 3)
336 (group 4)
436 (group 5)
Group mute control
Write
1 bit
1.003
C-W--
Rubric:
Group volume
Data type:
Enable
Function:
Group 1/2/3/4/5 – Mute the music output of the group
Description:
Group muting: Switches the loudspeakers of the group off (1) or on again (0).
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
37 (group 1)
137 (group 2)
237 (group 3)
337 (group 4)
437 (group 5)
Group mute state
Read
1 bit
1.003
CR-T-
Rubric:
Group volume
Data type:
Enable
Function:
Group 1/2/3/4/5 – Indicates whether all music players in this group are muted.
Description:
Supplies the status of group muting: 1 = Loudspeaker off, 0 = Loudspeaker on.
