ISE Sonos - Page 40

ise smart connect KNX Sonos
Configuration
Order No. 1-0001-002
Product Manual Page 40 (76)
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
32 (group 1)
132 (group 2)
232 (group 3)
332 (group 4)
432 (group 5)
Group volume control
Write
1 byte
5.001
C-W--
Rubric:
Group volume
Data type:
Percent (0 to 100%)
Function:
Group 1/2/3/4/5 – Set group volume (absolute)
Description:
Enables setting of the group volume over the bus: 0 corresponds to 0%, and
255 to 100% volume
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
33 (group 1)
133 (group 2)
233 (group 3)
333 (group 4)
433 (group 5)
Group volume state
Read
1 byte
5.001
CR-T-
Rubric:
Group volume
Data type:
Percent (0 to 100%)
Function:
Group 1/2/3/4/5 – Current group volume
Description:
Supplies the value of the group volume over the bus: 0 corresponds to 0%, and
255 to 100% volume
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
34 (group 1)
134 (group 2)
234 (group 3)
334 (group 4)
434 (group 5)
Group relative volume control
Write
4 bit
3.007
C-W--
Rubric:
Group volume
Data type:
Dimmer step
Function:
Group 1/2/3/4/5 – Turn group volume up or down
Description:
Enables the relative adjustment (louder/quieter) of the group volume over the
bus. Suitable transmitters include push button sensors with the "Brighten/Dim"
function, for example.
