Iseo X1R Smart - User Manual

Other manuals for Iseo X1R Smart

Installation Guide8 pages

Questions and Answers

T
taylorrobertAug 16, 2025
What to do if Iseo x1R lock doesn't close or open?
- J
  Jason PayneAug 16, 2025
  If your Iseo x1R lock doesn't close or open and the motor sounds strained, accompanied by an error signal after three attempts, it's likely that the bolts or latch are unable to move freely. First, ensure that the door closes properly and is correctly aligned. Next, use the key to verify that the bolts smoothly enter the strike holes with adequate space. When the door is open, confirm that the lock functions correctly with the mechanical key and electronically via the door sensor contact. Also, check the connecting rods to ensure they are not blocked and have at least 1 mm of play. You can also test the lock with the rods disconnected to further diagnose the issue.
P
phyllis16Aug 19, 2025
Why my Iseo x1R lock doesn't respond to any command?
- T
  Thomas SinghSep 12, 2025
  If your Iseo x1R lock isn't responding to commands, the latch and bolts aren't moving, and the command modules are off with no sound, it indicates the lock isn't powered. Check the batteries' status and the main power supply if one is present. Inspect the power supply cable for proper connection and any damage, and ensure the connector isn't broken or has loose contacts. If the problem persists, contact IseoZero1 Technical Support.
M
mary21Aug 22, 2025
How to fix Iseo x1R lock when the motor sounds like free rotating?
- S
  Stephanie GoodAug 22, 2025
  If your Iseo x1R internal motor sounds like it's freely rotating, and the latch and bolts are not moving, it means the motor cannot engage the internal lock mechanism. Check that the cylinder cam is in the correct (zero) position. Try opening the lock using the internal handle (if it's a Single Action lock) or the mechanical key to unlock the motor. Also, verify that the cylinder is the correct model and that the lock is installed correctly, referring to the Warnings section of the installation guide. If the issue persists, contact IseoZero1 Technical Support.
M
Marissa FernandezAug 25, 2025
Why does my Iseo x1R lock emit 2 acoustic signals?
- J
  jcabreraAug 26, 2025
  If your Iseo x1R lock, with the door closed, periodically emits two acoustic signals along with two slow red light signals, it means the latch is not fully inside its seat, usually due to excessive friction or a misaligned door. Check that the latch seat is properly sized and aligned with the latch when the door is closed. Also, check the distance between the door and the frame, and see if the issue is caused by pressure from the door sealing.
J
Jason YoungAug 28, 2025
What to do if Iseo x1R doesn't engage bolts when door is closed?
- T
  Timothy GriffinAug 28, 2025
  If your Iseo x1R, with the door closed, doesn’t engage the bolts but shows correct light and sound behavior, it's likely that the Passage Mode or Scheduled Passage Mode is enabled. To resolve this, disable these modes. Also, check if the door sensor contact has been installed with the correct polarity and is making proper contact. If not, adjust the position of the contacts or replace the door sensor contact.
K
kyle86Aug 31, 2025
Why does the latch keep inside the Iseo lock?
- H
  harrisrebekahAug 31, 2025
  If the latch of your Iseo lock keeps retracting into the lock, it could be due to several reasons: Passage Mode being enabled, the remote opening button being continuously pressed, or the latch being mechanically stuck. To solve this, disable the Passage Mode or Scheduled Passage Mode. Ensure the remote opening button is not stuck or disconnected. Also, try to manually unlock the latch.
K
Kenneth GibbsSep 3, 2025
Why doesn't the external control module react to RFID or PIN on my Iseo lock?
- M
  melanie00Sep 3, 2025
  If the external control module of your Iseo x1R Smart lock isn't reacting or responding to any RFID or PIN credential and isn't giving any light or sound signals, it could be due to a disconnected or damaged wiring, or a faulty external control module. Check the wiring of the external control module to ensure it's not damaged and the connector is securely attached to the x1R Smart. Try switching the x1R Smart off and on; upon reboot, the lock will attempt to communicate with and update the external control module if necessary. You can also try using another external control module to see if the problem is resolved.
N
Nicole RobersonSep 6, 2025
What to do if Iseo x1R lock doesn't respond to any command and emits 7 acoustic signals?
- D
  david59Sep 6, 2025
  If your Iseo x1R lock doesn't respond to any command, the latch and bolts don’t move, the control modules emit seven acoustic signals along with seven fast red blinks, and opening via smartphone is denied, it indicates an internal logical error compromising the software functionality, possibly due to a broken or uncalibrated internal sensor. Check if the x1R Smart version in the Advanced menu corresponds to the lock code on the lock case label. Contact IseoZero1 Technical Support for the automatic sensor calibration procedure.
J
James SimmonsSep 9, 2025
Why is Iseo x1R not visible on Argo app?
- B
  bwrightSep 9, 2025
  If your Iseo x1R is not visible on the Argo app, and the external and internal modules are flashing red at regular intervals without any sound, it indicates that the Bluetooth module is either not connected or not working. Check the Bluetooth module cable to ensure it is intact and well-connected on both ends. If the issue persists, replace the Bluetooth module.
P
Phyllis PearsonSep 12, 2025
Why does my Iseo lock switch off when I open the door?
- S
  Stephanie Owens DDSSep 12, 2025
  If your Iseo lock switches off (control modules LED off) as soon as you open the door, it's likely powered by door sensor contacts and the battery is low. Replace the batteries to solve this issue.

Summary

About this manual

Information icons

Explains icons used for warnings, cautions, and notes for clear manual reading.

How to use this manual

Guide on navigating the document using the Table of Contents for direct access.

Information on copyright

Legal statement regarding the reproduction and distribution of the manual content.

Trademarks

Lists intellectual property marks associated with the product and related technologies.

Keywords

Glossary of terms and definitions used throughout the user manual for clarity.

Safety and Environment

Safety information

Crucial precautions to prevent product damage and personal injury during use.

Disposal and recycling

Guidelines for environmentally responsible disposal of the product and batteries.

Certifications and compliance

Lists standards and regulations the product adheres to for quality and safety.

Classification digits explanation

Details the meaning of classification codes based on EN standards for product performance.

Overview

What is x1 R Smart

An introduction to the electronic motorized lock and its primary functions.

System components

Details the various parts and accessories that make up the x1R Smart system.

Technical data

Provides specifications, features, dimensions, and operating parameters of the x1R Smart.

Dimensions

Visual representation and measurements of the lock's physical size and key features.

Options and versions

Describes different configurations and available models of the x1R Smart lock.

Electrical connections (standard)

Wiring diagrams and instructions for standard electrical hookups.

Example of 8 poles Multifunction Cable wiring scheme

Illustrates a specific wiring example for the multifunction cable.

Getting Started

Package contents

Lists all items included in the product box upon purchase.

Product identification

Explains how to find and understand the product's identification label.

Product codification

Details the structure and meaning of the product's unique identification code.

Installing x1 R Smart

Provides instructions or refers to a guide for the physical installation of the lock.

First switch on

Steps to follow when powering on the device for the very first time.

Device Initialization

Process for setting up the device, including factory mode and initial configuration.

Add credentials without Argo App

Instructions for adding access credentials like cards or tags manually.

Add a PIN code without Argo app

Steps to create and add PIN codes for access without using the app.

Adding credential by Argo app

Guide on using the Argo app to add smartphones, cards, or tags as credentials.

Adding a PIN code by Argo app

Instructions for adding PIN codes for access using the Argo smartphone application.

Basics

How to use x1 R Smart

Explains the various methods for operating the lock from both external and internal sides.

Door Info menu

Describes the menu within the Argo app for viewing lock status and settings.

Advanced

Versions

Displays serial numbers and software versions for the lock's electronic components.

Advanced settings menu

Details parameters that can be adjusted for personalized lock behavior.

x1 R Smart Version

Explains how to select and configure the lock's operational version (Standard/Single Action).

x1 R Standard

Specific options and configurations available only for the Standard version of the lock.

Passage Mode configuration

How to set the lock to operate in 'Light' or 'Free' passage modes.

Reset

Options for restoring default settings or performing a full factory reset of the lock.

Door status relay

Explains the function of the output relay for indicating door status (open/closed).

Single pulse

Describes how the relay can provide a single pulse output for specific applications.

Remote opening command

How to connect and use external devices for remote door opening commands.

Door sensor contact

Explains the function and installation of the door sensor for status detection.

Door sensor contact in the hinge side of the door

Specific installation details for the door sensor on the hinge side.

x1 R Smart as actuator

How to use the lock as a simple actuator for opening/closing actions.

Enable Actuator mode

Instructions for configuring the lock to operate in actuator mode using a jumper.

Actuator mode and Argo

Explains limitations and features when the lock is in actuator mode with the Argo app.

Actuator mode and door status relay

Describes relay behavior when the lock is configured as an actuator.

More advanced function about Argo app

Points to further features and capabilities available through the Argo app.

Maintenance

Battery replacement

Step-by-step guide on how to replace the lock's batteries.

Notes on battery usage by x1 R Smart

Information on battery behavior and replacement based on different power configurations.

Cleaning

Instructions on how to clean the lock's surfaces safely and effectively.

Storage

Guidelines for storing the lock when not in use for extended periods.

Appendix

Events log messages

Explains the meaning of various event codes recorded by the lock system.

Light and acoustic signal

Details the meaning of LED and audible signals emitted by the lock.

Wiring specifications

Provides guidelines for power supply voltage and wire gauge based on distance.

Why some Functional Modes are no more present on Argo

Explains changes in functional modes in newer software versions.

Troubleshooting

Argo app error messages

Directs users to the Argo User Manual for troubleshooting app-specific errors.

x1 R Smart troubleshooting

Provides solutions for common issues encountered with the x1R Smart lock.

Technical assistance

Information on how to contact support and what details to provide for troubleshooting.

Iseo X1R Smart Specifications

General

Power	Battery
Connectivity	Bluetooth
Power Source	4 AA Batteries
Battery Life	Up to 2 years
Communication	Bluetooth
Material	Steel
Security	AES 128 bit encryption
Installation	easy installation
