ITech IT-M7700 Series User Manual

Quick Reference
When the number before the menu item is in a flashing status (the digit is flash-
ing while the colon is not flashing), it indicates that this item is the selected
menu. The descriptions of configuration menu are listed in the table below.
Table 1–3 IT-M7721/IT-M7722/IT-M7722D/IT-M7723D/IT-M7722E/IT-M7723E menu
Config Configuration menu
I Range Set the current measurement range.
High
High range(Applicable frequency
range: 45Hz ~ 1000Hz)
Low
Low range(Applicable frequency
range: 45Hz ~ 100Hz)
Auto
Auto range. The range is automati-
cally switched between High and
Low based on the measured cur-
rent. (Applicable frequency range:
45Hz ~ 100Hz)
AC + DC
Set the AC + DC output mode.
Off
Turn off AC + DC output mode.
On
Turn on AC + DC output mode.
On Phase
Set the starting phase angle of the waveform. (only displayed
under the AC Mode)
Off Phase
Set the ending phase angle of the waveform. (only displayed
under the AC Mode)
V-Rise Time
Set the voltage rising time. (only displayed under the DC
Mode)
Wave
Set the output waveform type. (only displayed under the AC
Mode)
Sine Sinusoidal
Square Square
Triangle Triangle
Saw Sawtooth
Clip Sine Clipped Sinusoidal
Clip Level Clipped Percentage
THD1~THD30 30 sets of built-in waveforms.
USER1~USER5 5 sets of user-defined waveforms.
Parallel
Set the instruments to 3-phase or series operation mode.
Single
Set the instrument to single mode,
i.e., disable the 3-phase or series
operation mode.
Copyright © Itech Electronic Co., Ltd.
11
